Instead of the buzzer it is possible to combine a splendid display with LED lights, the signaling occurs through the lighting of the LEDs and the sound signal increases as the distance from any obstacle decreases (people, walls, poles or kerbside even low to bumper height, others vehicles).
Display compatible with the models:
|dimensions||A: 10 x B: 2 x 2.5 cm.|
|Cable length||6 meters|
|Connection||to the front / rear parking sensor control unit|
|Compatible with CAN BUS and CHECK CONTROL|| |
No interference with other on-board equipment
when reversing (rear) and pressing the button (front)
|Installation||above the bridge|
|fixing||double 3M adhesive|
Bright LED display and built-in buzzer .
1) The first 2 green LEDs inform the driver that an obstacle is approaching.
2) The three yellow LEDs light up in sequence when the obstacle arrives near the bumper at a distance varying from 15 to 30 cm depending on the type of obstacle. These values correspond to the central area of the bumper while on the corners the distance is less.
3) The two red LEDs will light up when an obstacle is very close to the bumper (15-10 cm) to give an alarm of possible contact.
|For more information and technical characteristics go to our website: www.proxel.com|
